YANTON TM-8600 60W 400-480/136-174MHz Mobile Radio Scrambler Encryption Function Car Radio

Original price was: $478.50.Current price is: $258.87.

Availability: 50 in stock

SKU: 3256807155261888 Category: Tag:

Free Shipping Yanton TM-8600 FM walkie talkie 60w UHF400-480MHz mobile radio talkie-walkie 25KM

1.CTCSS/DCS setting & scanning
2. 1750Hz Tone
3.High/Mid/Low power selectable
4.Voice compander
5.ANI ID
6.DTMF/2 tone/5 tone
7. Remote kill/ stun/ activate/ revive
8.Emergenvy alarm
9.Wide/Narrow band setting

GENERAL
Frequency Range
 136-174/245-246/400-490MHz
Operating Temperature
2.5ppm
 Operating Temperature
-20℃~+60℃
Operating Voltage
13.8VDC±15%
Memory Channel
199channel
Dimension(HxWxD)
145mmX190mmX47mm
Weight(with bracket)
1200g
TRANSMIT PART
RF power
45W/25W/10W(UHF)
60W/25W/10W(VHF)
Frequency modulation
 11kΦF3E/16kΦ F3E
Modulation distortion
<5%
FM noise
≥36dB@KHz
≥40KHz@25KHz

Adjacent Channel Power
Audio Response

Audio Distortion

≥60dB 12.5KHz

≥70KHZ 25KHz
+1-+3dB
<5%

RECEIVER PART
Adjacent channel selectivity
0.25v/0.35v
Inter-modulation Rejection
≥60dB/≥65dB
Spurious Response Rejection
≥70dB
Rated Audio Response
Rated audio
distortion

+1-+3dB

<5%
FM Hum &Noise
≥40d25KHz
≥45KHz12.5KHz
FM Hum &Noise
≥40dB 25KHz
≥45KHz 12.5KHz
Weight 0.9 kg
Dimensions 400 × 500 × 200 cm
